Morehouse Load Cell Amplifier

This Load Cell Amplifier (LAC) is the best-performing we have ever tested, so we decided to sell it.

The LAC is a universal analog amplifier designed for static/semi-dynamic force measurement applications in industrial environments. These units work exceptionally well when paired with Morehouse load cells.

The LAC's high accuracy and stability are unique compared to the regular amplifiers available.

These features become more important for force measurement applications than for other measurements since the application of load in industrial setups often involves some vibration.

The exceptional accuracy and stability of the LAC enable you to get the best out of your force measurement instrument and make programming your control system much easier.

Features include:

• Offers extreme stability and security in hostile, industrial environments
• Both bipolar voltage output ±10V and current output 0-20 or 4-20mA
• Zero, span, and filter settings are performed via firm DIP switches in binary organized steps and finely trimmed by 20-turn pots to achieve a very high resolution
• Both voltage and current output are available at the same time to allow for dual readouts at two locations
• Can drive up to 8 Pc 350-ohm load cells, or 24 Pc 1000-ohm load cells
• A wide range of gain and virtually no zero drift enables a live range down to a few percent of the load cell's rating
• Wide range of selectable low pass input filters from 33 to 0.33Hz to meet any requirement
• AC excitation voltage (425Hz) cancels the influence from EMI and thermos-electric forces from wire joints
• Low 2.5V excitation voltage effectively prevent load cell warm-up errors
• The wide supply voltage range and the isolated power supply underline the electrical robustness
• The layout of the front and the LED indicators ease the setup and calibration
• Can be clipped onto various DIN rails and offers robust screw terminals for all connections
