Easy to Use Wireless Handheld Indicator Kit

T24 Wireless Handheld Indicator kit consisting of T24-HA receiver, T24-ACMi-SA, with setup (wiring) and programming by Morehouse. The T24 handheld kit gives you the best option to display data from up to 12 wireless transmitter modules sensors that are a modular wireless solution for industrial sensor applications including Morehouse shackle pins, load cells, and other rigging or lifting equipment.

Wireless Handheld Indicator Kit

The T24 wireless handheld indicator kit is the best option for displaying data from up to 12 wireless transmitter module sensors. It is a modular wireless solution for industrial sensor applications, including Morehouse shackle pins, load cells, and other rigging or lifting equipment.

The data sent by transmitter modules can be utilized by multiple receivers such as displays, handheld readers, analog outputs, relay modules, and computer interfaces. Receivers support standard industrial power supplies and are available in robust IP-rated enclosures with internal antennas optimized to give outstanding coverage.

The T24-ACMi-SA Wireless Handheld Indicator provides a summed total from all selected transmitters or the ability to view individual transmitters. It is powered by two AA batteries and is designed for low-power operation.

  •  Receives data from up to 12 wireless transmitters (easily connected to load cells)
  •  Summed total of inputs feature
  •  Auto ‘power on’ and ‘power off’
  •  Simple wireless configuration and calibration
  •  Wireless range of up to 800 m (2,600 ft)
  •  Battery powered 40 hours use
  •  Waterproof to IP67

T24 Wireless Telemetry Sensor System is a modular wireless solution for industrial sensor applications. High accuracy and high-quality measurement are interfaced with simple yet powerful configuration and monitoring software.

  •  Wireless range up to 800 m (2,600 ft)
  •  Internal batteries (2 x AA)
  •  Waterproof to IP67 enclosure 80 x 62 x 34 mm
  •  Exceptionally low power for long battery life
  •  Remote power ‘on’ and ‘off’
  •  Easy connectivity to a variety of sensors
  •  High speed - up to 200 updates per second
  •  High Resolution up to 1 part in 400,000 (18bit)

*With setup (wiring) and programming by Morehouse using deadweights up to 120,000 lbf to get the readings as close to the nominal values as possible.

The wireless handheld indicator by Morehouse is perfect for those wanting a wireless solution connected to almost any existing load cell. Morehouse can supply premium calibration, custom cases, load cells, and other adapters to make a complete calibration package with this wireless handheld indicator.

Morehouse Free Calibration Software: Download Today
Morehouse calibration software allows readings from any number of Morehouse indicators that have a communication output (USB or serial). If multiple indicators are used, their values can be added together to show a total value. The software can do the unit conversion (between force units and mass units), and mass conversion, and adjust the resolution at the values shown, and much more!

Product Photos

When You're Looking for More Accurate Measurements

Morehouse would like the opportunity to earn your business. Contact us today.
